RENA Vivo ozone system
Ozonetech RENA Vivo – The most effective treatment system for process equipment and water sanitation
Ozonetech’s RENA Vivo segment is a series of turn-key CIP systems used in the food, beverage and brewing facilities, aquaculture, dairy production, as well as the pharmaceutical industry and off-shore. RENA Vivo is an ozone system used for aqueous ozone applications for sanitation of process equipment, quality assurance of process water and treatment of wastewater.
The system has a control system with an intuitive HMI, regulation and control of ozone production, integrated oxygen generators. The RENA Vivo segment always employs oxygen fed ozone generators with high ozone concentrations for maximum efficiency.
The Vivo segment offers the following operational enhancements:
- Cut CIP cycle time by 20-30 minutes due to shorter sanitation and rinse-free operation
- Eliminate all disinfection agents used for treatment or sanitation
- Reduce energy requirements by replacing hot water with cold ozone sanitation
- Ensure completely microbial free water
- No handling of chemicals, transport and costs
- Treat complex wastewater substances on site
- Chemical-free feed and process water quality assurance
Left: RENA Vivo B-series front. Right: RENA Vivo B-series back.
Differences between RENA Vivo models
RENA Vivo A-series
The RENA Vivo A-series is a highly efficient system, tailored for smaller food & beverage facilities, craft breweries and treatment of smaller waste streams in various industries for Clean-in-Place (CIP) and water treatment. It effectively produces ozonated water in a compact design, 120x80x180 cm. Power input is very low at maximum 900W during operation.
RENA Vivo B-series
The B-series is Ozonetech’s tailored system for larger production facilities for Clean-in-Place applications for breweries, large dairy facilities and pharmacetical production. It still a compact system sized 120x80x270 cm.
RENA Vivo C-series
The C-series is our highest capacity ozone system, tailored to solve complex treatment challanges such as break-down of pharmaceutical residues or complex substances. It is a perfect solution for ensuring large flows and volumes of high quality process water supply It is delivered with an integrated oxygen generator or external oxygen supply.
Please download our RENA Water Systems brochure here .
Unique features in one turn-key systems
Our RENA Vivo segment has been specifically designed to produce ozonated water for a variety of applications as one turn-key system. Below is a table with a summary of system-specific data:
| Feature | A-series | B-series | C-series |
|---|---|---|---|
| High-performance ozone generator with HELS™ technology | Always | Always | Always |
| Integrated oxygen generator | Typical | Yes | Stand-alone oxygen concentrator |
| Integrated ozone degassing | Always | Always | Always |
| Ozone destructor | Typical | Typical | Typical |
| Ambient ozone detector | Yes | Yes | Yes |
| Integrated contact and/or reaction tank | 50 L | 150 L | 300 or 500 L |
| Advanced Control System with HMI | Yes, 7″ touch panel | Yes, 9″ touch-panel | Yes, 9″ touch panel |
| Automatic ORP control | Yes | Yes | Yes |
| 1 ppm dissolved ozone flow capacity | 4-35 m3/hr | 18-110 m3/hr | 35-210 m3/hr |
| Hydraulic connections | DN25 | DN50 | DN50/65 |
| Dimensions (mm, HxLxW) | 1800x1200x800 | 2128x1200x800 | 2092x1600x1200 |
Sizing guideline
Indication of RENA Vivo series selection for sanitation of process equipment CIP or quality assurance of process water. Recommendations for 3 log inactivation of bacteria in 10 minutes.
| Volume (m3) | Flow (m3/hr) | ||||
|---|---|---|---|---|---|
| 10 | 15 | 20 | 30 | 50 | |
| 0.2 | A | A | B | B | B |
| 0.5 | A | A | B | B | B |
| 1 | A | A | B | B | B |
| 5 | B | B | B | B | C |
| 10 | C | C | C | C | C |
| 15 | C | C | C | C | C |
